Laser layout tools

Explore our range of lasers, optical levels and other standard layout tools designed for intuitive levelling, squaring and alignment tasks

12 Products

Filter

Nuron

undefined

PR 40-22 Single slope rotating laser level

Nuron

 Nuron
Description
Robust exterior rotary laser level with automatic functions for long-distance leveling, aligning, sloping and squaring (Nuron battery platform)
Accuracy
±1.5 mm at 30 m
Laser class
<4.85 mW, 620-690 nm, Class 2 (EN 60825), Class II (FDA CFR 21 art. 1040)
Self-levelling range at room temperature
±5(± 8.7%) °
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.

Nuron

undefined

PM 50MG-22 multi-line laser

Nuron

 Nuron
Description
High visibility self-levelling laser with 3 green 360° queues and 15+ hours of run time for leveling, aligning, squaring and plumbing (Nuron battery platform)
Accuracy
±3 mm at 10 m
Max. operating distance (diameter)
80 m (lines), 130 m (lines, with receiver)
Battery type
22 V
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
undefined

PM 30-MG Multi-line laser level

12 V
Description
Compact multi-line laser - 3x360° self-levelling green lines for faster levelling, aligning and squaring (12V battery platform)
Accuracy
±3 mm at 10 m
Max. operating distance (diameter)
40 m (lines), 100 m (lines, with receiver)
Self-levelling range at room temperature
-4.0/ +4.0° °
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
undefined

PM 40-MG Multi-line laser

12 V
Description
Multi-line laser with 3 green lines for plumbing, levelling, aligning and squaring
Accuracy
±2 mm at 10 m
Max. operating distance (diameter)
40 m (lines), 100 m (lines, with receiver)
Self-levelling range at room temperature
-3.0/ +3.0° °
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
undefined

PM 20-CG 12V Plumb and cross line laser

12 V
Description
Green beam combi-laser with 2 queues and 4 points for plumbing, leveling, aligning and squaring (12V battery platform)
Accuracy
±3 mm at 10 m
Max. operating distance (diameter)
40 m (lines), 100 m (lines, with receiver)
Maximum operating time
33 h

New

undefined

PM 2-PG Green plumb laser

New

Description
Green point laser with 2 high-visibility dots for transferring points vertically and establishing plumb
Accuracy
±3 mm at 10 m
Max. operating distance (diameter)
40 m (points)
Maximum operating time
60 h
undefined

PM 2-PE Point laser

Description
High-precision plumb laser with 2 points and red beam
Accuracy
±1.5 mm at 10 m
Max. operating distance (diameter)
30 m (points)
Maximum operating time
50 h
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.

New

undefined

PM 2-LG Green line laser

New

Description
Green line laser with 2 high-visibility beams for levelling and aligning
Accuracy
±3 mm at 10 m
Max. operating distance (diameter)
40 m (lines), 100 m (lines, with receiver)
Maximum operating time
8 h
undefined

POL 15 Optical level

Description
Optical level for everyday levelling tasks with 28x magnification
Magnification
28 x
Compensator type
Air-damping
IP protection class
IP 55 (EN 60529)
undefined

PR 300-HV2S Outdoor rotating laser level

Description
Outdoor rotary laser level with automatic vertical alignment and dual slope dial-in functions for levelling, aligning, grading and squaring tasks
Accuracy
±0.5 mm at 10 m
Operating range with laser receiver (diameter)
2 - 600 m
Laser class
<4.85 mW, 620-690 nm, Class 2 (EN 60825), Class II (FDA CFR 21 art. 1040)
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
undefined

PR 2-HS A12 Outdoor rotating laser level

12 V
Description
Robust outdoor rotary laser level for horizontal levelling
Accuracy
±0.5 mm at 10 m
Operating range with laser receiver (diameter)
2 - 600 m
Laser class
<4.85 mW, 620-690 nm, Class 2 (EN 60825), Class II (FDA CFR 21 art. 1040)
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
undefined

PR 30-HVSG A12 Indoor rotating laser level

12 V
Description
Indoor rotary laser level with highly visible green beam and automatic functions for virtually any interior jobsite layout tasks
Accuracy
±1 mm at 10 m
Operating range with laser receiver (diameter)
2 - 300 m
Laser class
<4.85 mW, 510-530 nm, Class 2 (EN 60825), Class II (FDA CFR 21 art. 1040)
Unique measuring performance. Hilti Pulse Power works with up to 1 million impulses per second, allowing for highly reliable readings even under the most difficult conditions.
