HOW WE CAN HELP TO ANALYSE CONCRETE SCANS

If you’d like help with analysing data from your scans using our Hilti PS 300 Ferroscan or Hilti PS 1000 X-Scan detection systems, then you can contact your local Hilti team.

We have Hilti experts who can look at your scan data and optimize the data for you, exporting it in the needed format in 2D or 3D.

This covers:

Rebar

Find the location of the reinforcing bars and estimate the depth of concrete cover and rebar size – based on scan data from our Hilti PS300 Ferroscan. This is important for as-build checks, structural renovation work or retrofitting.

Layout and type of objects

Analyse the layout of objects, using scan data from our Hilti PS 1000 X-Scan detection system. Find rebar, live wires, metal or plastic pipes and more, and analyse their layout over a wide area and multiple layers.

Please contact your local Hilti team for more information.
